JETCONTROL 600 (S SERIES)

JETCONTROL 600 (S Series) are single stage, two gauge cylinder regulators extensively used in oil refineries, refrigeration laboratories or industrial processes requiring precise and stable delivery of high pressure industrial gases. It is excellent tool for high pressure testing of vessels and various pipelines for gas and liquid supply.

Regulators are primarily designed, tested and manufactured to operate on max. inlet pressure up to 300 Bar and providing pressure outlet up to 206 Bar. Its robust design, top grade materials and strictly controlled manufacturing and testing procedures guarantee high operational safety even if working with small molecular gases (like helium or hydrogen) at very high pressures.

Key components are manufactured from high tensile brass, use of extra safe and accurate bulkhead gauges, double layer high grade stainless steel diaphragms and efficient metal filters help to prolong regulator service life and ensure trouble-free operation of JETCONTROL 600 (S Series) regulators.

FEATURES, ADVANTAGES, BENEFITS

Top-safe & Accurate Bulkhead 50mm Gauges
Transparent powder-painted surface for high corrosion resistance
Body, bonnet and inlet stem made from high-tensile brass
Technical Data permanently marked on rear side of body
Double-layer pre-shaped stainless-steel diaphragm
Outlet connections compatible for instant use of Parker fittings
Bronze bush to reduce friction
Massive T-bar for easy pressure setting

TECHNICAL DATA

Body:	High tensile brass, chemically stabilized and transparent powder-painted
Bonnet:	Brass, chemically stabilized and transparent powder painted
Diaphragm:	Two layer, diam. 40 mm, pre-shaped stainless steel
Encapsulated valve:	Brass body sealed by high-grade PA
Pressure Gauges:	Safe design, bulkhead 50mm gauges, scale in Bar, accuracy class 2,5%
Inlet Stem & Nut:	High-tensile brass, geometry complying with BS-341 standard
Safety Valve:	Not-present, must be an independent part of downstream gas line
Pressure Setting:	Stainless steel T-bar, brass pressure adjusting screw in bronze bush
